Material And Model Thickness 40mm
Maximum specification Maximum width is less than or equal to 6m, height is arbitrary.
Frame material Precision extruded 6061 aerospace aluminum
Structural design Anti-pinch door panel connection, torsion spring anti-breakage, door panel anti-fall, multiple safety designs such as photoelectric
Color Conventional colors include white, black, yellow, etc. More than 10 colors are available
(various standard colors can also be provided according to building requirements).
Transparent panels Can be made of polycarbonate endurance board (PC board), acrylic board, tempered glass, coated glass, low-e glass, hollow glass, etc., thickness from 3mm to 16mm, can be selected according to door width.
Main functions of the door opener motor
• Adjustable opening and closing speed
• Self-monitoring and automatic shutdown in
case of obstacle rebound
• Support for smartphone-controlled intelligent
door control system
• Quick emergency disengagement
• Low voltage/overload/overheat self-protection
• Remote control self-learning
• Maintenance reminder
• Public place safety (multiple users)
• Ventilation function
• Counting function
• Built-in WiFi function
• Bluetooth APP control
(controllable up to 50 meters away)
